Barrier Blocks
Series 140
.375 Density, 5-40 x 3/16"
BH Screw, Open Bottom,
Double Row
Electrical Characteristics
Voltage Rating: 250 VAC RMS maximum
Current Rating: 15 Amps maximum
Maximum Watts Per Terminal: 3750
Mechanical Characteristics
Maximum Wire Size: #16 AWG
Recommended Tightening Torque: 9 lb.-in.
Dimensions
Ordering Information
No. of Standard Screw
Terminals Catalog No.
1 1-140
2 2-140
3 3-140
4 4-140
5 5-140
6 6-140
7 7-140
8 8-140
9 9-140
10 10-140
11 11-140
12 12-140
13 13-140
14 14-140
15 15-140
16 16-140
17 17-140
18 18-140
19 19-140
20 20-140
21 21-140
22 22-140
23 23-140
24 24-140
25 25-140
“M”
Dim.
.750
1.125
1.500
1.875
2.250
2.625
3.000
3.375
3.750
4.125
4.500
4.875
5.250
5.625
6.000
6.375
6.750
7.125
7.500
7.875
8.250
8.625
9.000
9.375
9.750
“L”
Dim.
1.032
1.407
1.782
2.157
2.532
2.907
3.282
3.657
4.032
4.407
4.782
5.157
5.532
5.907
6.282
6.657
7.032
7.407
7.782
8.157
8.532
8.907
9.282
9.657
10.032
Call Toll Free: 1 (800) 323-9612
2-4
Marketed exclusively through distribution.
